Réf 14748

Flymaster - Nav C

Nouveau navigateur de la série C

Disponibilité :

En stock fournisseur - délai entre 1 et 3 mois
800,00 €
TTC
Option 1
Ajouter au panier
  • Carte VIP offerte à partir de 1 000€
  • Livraison gratuite en France dès 100€
  • Livraison gratuite en UE/CH/UK dès 500€
  • Paiement en plusieurs fois dès 1 000€

C from color. C from competition.

Introducing the NAV C: where the DNA of the NAV SD meets the spirit of the LIVE DS, resulting in a lightweight and versatile single-display marvel. It's the ultimate fusion, offering the best of both worlds without compromising on performance. Embrace a new era of navigation excellence with the NAV C.

Main Hardware Characteristics

Type d'affichage Reflective colour 640x480px
Capacité de la batterie (lithium-ion) 6000 mAh
Autonomie Learn more Usually more than 24 hours (environment conditions may alter this value)
Size 152x90x18 mm
Poids 200 g
Statut GPS 72 channel U-blox BeiDou, Galileo, GLONASS, GPS / QZSS
Connexion USB native USB Type-C Mass Storage Access
Batterie en charge From wall adapter or standard usb port
Bluetooth Bluetooth 5 low energy module
FlarmFlarm Flarm ready (optional Flarm Aware RX + TX mode)
Micro SD Prend en charge les cartes mémoire SD jusqu'à 256 Go.
6 Axis accelerometer and magnetometer Allows 6-degrees of freedom Tilt-compensated Compass)
Firmware update by USB (upgrades are free)

Interface Features

User definable pages (each page can be draw using Flymaster Instrument Manager, and include a number of elements only limited by space). 8 page sets
Configurable graphical elements (depending of the element several parameters can be set by the user ex. Size, Border, Color, ...) 15
Configurable data field elements (User can change size, border, title, Font, Color, ...) 85
Page Trigger Events (page switches automatically if a specific event occurs)
  • Airspace warning
  • Entering thermal
  • Transition (leaving thermal)
  • Arriving at turn point
  • Start opened
  • Power up
Interface language English
Configurable voice alerts
  • Airspace
  • Turn point complete
  • Start opened
  • Goal Possible
  • Distances
  • Countdown time

Caractéristiques du variomètre / altimètre

  • Buzzer/near thermal sound
  • Ultra sensitive Variometer with 10 readings per second and 10 cm resolution
  • Configurable vario digital filter and integration values
  • Fully configurable Vario Sound (frequency, increments, frequency/vertical speed relation,….)
  • Adjustable Sound Levels
  • Automatic mute, keeps vario silent until takeoff
  • Altitude adjustment using QNH
  • Automatic altitude adjustment from GPS
  • 2 independent altimeters

Caractéristiques de la mémoire

3D flight logger IGC format

3D Airspace

  • La carte offre une visualisation intuitive des zones restreintes, garantissant une identification facile et une prise de conscience des zones interdites.
  • Adjustable voice warning of vertical distance to a restricted area
  • Adjustable voice warning of horizontal distance to a restricted area
  • Display of shortest vertical, and horizontal distance to restricted area
  • Restricted area voice alarms (Altitude imminent, Position imminent, Violation, …)
  • Critical Airspace page (displays information about areas that are closer than a defined distance)
  • Airspaces browser
  • Worldwide Airspace database

Maps

  • Detailed colored maps with topographic data
  • With configurable layers

Cross Country Features

  • Exclusive Thermal Ball indicator
  • Several specific data fields like distance to take off, current and average glide ratio, average speed, etc.
  • Distance to last thermal indexed with altitude
  • Goto waypoint
  • Multiple waypoint route
  • Wind Speed and Direction (GPS based calculations)
  • Automatic altitude gain profiler
  • Nearby Landings (displays required glide ratio and distance to all the landings which can be reached)

Competition Features

  • Route Optimization (indication for shortest route point)
  • Speed to Start (optimal speed to make the start)
  • Arriving altitude at next waypoint and goal (considering wind)
  • Several Glide Ratios (to goal, average, to next,…)
  • Easy task definition
  • Task Navigation, configurable safety/risk margin on turn points.
  • Task Map (trace with thermal indication)

Interface

Compatible avec MacOS (10.13 and higher), Windows (7/8/10)

GPS Oui
Catégorie - Instrument .Vario-gps
Catégorie Instruments Marque Flymaster
